5 Foot Cable Ladder Rack Kit - Heavy Duty Cable Management System for Home & Office Organization - Perfect for Server Rooms, Data Centers, and Network Wiring Installations

Description

5-Foot Cable Ladder Rack Kit, 5' x 12"

Our 5-Foot Cable Ladder Rack kit allows you to have the equivalent of 10 feet of ladder rack. Order our bundle kit and avoid incurring hefty surcharges applied by freight carriers.

Each kit includes (2) 5ft x 12” wide ladder sections and (1) butt splice kit, which when assembled creates 10 feet of ladder.

Features

Features

• Stringers: 1-1/2 x 3/8 x 0.06 thick tubular steel
• Cross Members: 1.00 x 1/2 thick tubular steel welded on 9.00 centers
• Max. load w/min. deflection: 132 lbs. per foot if supported every 5 feet
• Kit Includes: (2) 5 foot Ladder Rack Runways, (1) Butt Splice Kit

Specifications

Specifications

Technical Illustration

What’s In The Box

What’s In The Box

• (2) 5-Foot Ladder Rack Runways
• (1) Butt Splice Kit
